UP53 Dental Milling Machine

Smart dental 5-axis milling machine

Help the mass production Can control multiples dental milling machines simultaneously
Automatic calibration The most convenient and smart control system among the dental milling machines
	One-piece casting framework Portable, precise and great durability
Wide application Support multiple restoration cases
Ultra-thin veneer The P53 processing algorithm is greatly upgraded. which can stably cut the thinnest 0.15mm ultra-thin veneer.
	Supports the 90° vertical milling The 90° vertical milling method can make the design of the front teeth more aesthetic.
Leading the intelligent era of dental laboratories Resume，Automatically continue milling from the last interrupted step, avoiding repeated work and improving work efficiency by 80%.
	Tools lifetime display P53 is able to realize automatic calculation of tools lifetime reasonable planning of tools life cycle,and reduce the risk of zirconia breakage and milling failure with UPCAM.
UPCNC software One interface for multiple mills, easy to operate and one-click milling.	UPCAM NESTING Compatible with up3d smart milling machine P4, P5.

PRODUCT PARAMETERS
Model:P53

Dimension:443.5×718×628.5 （ m m ）

Weight:87Kg

Input voltage:AC 185~235V 、 50~60Hz

Max power:0.8KW

Spindle power:0.52KW（max）

Axis:5-axis simultaneous motion

Milling range:X/Y/Z :170/215/105mm  A:±30°  B : 360°

Milling mode:Dry milling

Max rotate speed:30,000rpm

Max feed rate:3000mm/min

Tool library:11

Tools changing:Automatic （ Air pressure >0.5MPa ）

Spindle cooling:Air compression （ Air pressure 0.25~0.35MPa ）

Milling materials:Zirconia, Wax, PMMA, PEEK and soft materials

Milling time:Coping:Zirconia-10min Wax- 4.5min
                    Crown:Zirconia-13min Wax-5.5min

Tools diameter:2+1+0.6 （ Φ 4 ）

KA51 Milling Machine

For Zirconia
Size: 53*47*56cm
Weight: 110Kg
Air Pressure:  0.6 ~ 0.8MPa
Power: ＜1.2kw
Processing Accuracy: ＜0.01mm
Burs Quantities:  6pcs (2mm, 1mm, 0.6mm, 0.3mm)
Voltage: 220V,50Hz or 110V,60Hz (Optional)
Spindle Speed:  80,000 rpm
Cooling Type: Air cooling
Processing Materials: Zirconia, PMMA, Resin, Wax，Modeling board
Processing Types:  Inner coping, Full crown, Bridges, Inlay, Veneer, Telescopic crown，Abutment crown, Dental model, Temporary crowns
Processing Speed:  Zirconia, PMMA, Resin (11 min/pcs), Wax (4 min/pcs)

XLC Cart for Aoralscan
The dedicated cart solution was designed to professionally round off the Aoralscan experience in a broad array of working scenarios.
